产品参数
| 加工板厚 Processing Plate Thickness | 0.4-6mm | 机器外侧宽度 Breadth of the machine | 4500mm |
| 加工板长宽 Length and Width of Machining Plate | 1500x4000mm | 机器外侧深度 Lateral depth of the machine | 1800mm |
| 切削速度 cutting speed | 5-70m/min | 机器总高 Total machine height | 1600mm |
| 送料速度 Feeding speed | 0.5-20m/min | 工作台长度 Workbench length | 4000mm |
| X轴最小设定单位 X-axis Minimum Setting Unit | 0.01mm | 机器重量 Machine weight | 11T |
| X轴定位精度 X-axis positioning accuracy | +0.02mm | ||
| Y轴最小设定单位 Y-axis Minimum Setting Unit | 0.01mm | ||
| Y轴定位精度 f-axis positioning accuracy | +0.02mm | ||
| Z轴最小设定单位 Z-axis Minimum Setting Unit | 0.01mm | ||
| Z轴定位精度 Z-axis positioning accuracy | +0.02mm | ||
| X轴电机功率 X-axis motor powet | 1.5KW | ||
| Y轴电机功率 Y-axis motor power | 3KW | ||
| Z轴电机功率 Z-axis motor PoVer | 0.4KW |
